MOTOTRBO Capacity Plus

Digital trunking solution

Download Brochure
Further information
Request price

Overview:

• Delivers 5 times the capacity of an analog conventional system and up to 3 times the capacity of an analog trunking system
• Delivers 2 times the capacity of a MOTOTRBO digital conventional system
• “Trunks” up to 12 digital voice talk paths
• Allows up to 24 additional dedicated data paths
• Accommodates up to 1,200 radios
• Integrates both voice and data applications such as GPS-enabled location services, text messaging, telemetry and much more, on the same system
• Offers system-wide calling capability to communicate with all personnel at once
• Supports the MOTOTRBO Repeater Diagnostic and Control (RDAC) utility to help ensure the continuous performance of your system
• Integrates with existing MOTOTRBO systems via a simple, software upgrade

SYSTEM CHARACTERISTICS

•  TDMA 2:1 technology
• Availablein UHF and VHF frequency bands
• Supports third party applications such as IP dispatch console with XRT 9000 gateway
• Peer site controller based architecture
• Uses rotating control channel (talk path)
• Redundant controller
• 15 repeaters per trunking site (29 voice/data talk paths)
• 35 trunking sites in a flexible system topology
• IP (Internet Protocol) site connectivity
• Supports DR 3000 or MTR3000 repeaters
• GPS-based location tracking (optional)

MAIN TRUNKING FEATURES

• PTT-ID
• Dynamic site assignment
• Site registration
• Automatic site roaming
• Busy queuing and call back with user priority levels
•  Selective call and call alert
• Multi-group call
• Radio disable/enable
• Radio check
• ESN system access verification
• Emergency operation
• Talk group scan
• Site restriction
• Optional man-down
